Advanced Process in PCB Assembly As electronic products evolve towards miniaturization, high performance, and high reliability, PCBA processes are continually innovating: High-Density Integration: To integrate more functions into limited space, PCBA processes constantly push boundaries, for example, by using smaller components, more precise routing, and multilayer PCB technology. Fine Pitch and Ultra Fine Pitch Assembly: As chip package lead spacing shrinks, it places higher demands on solder paste printing accuracy, placement precision, and soldering processes. Underfill Technology: For flip-chip packages like BGA and CSP, underfill technology is often used to fill epoxy resin between the chip and the PCB, enhancing mechanical strength and heat dissipation. Conformal Coating: For PCBAs operating in humid, dusty, or corrosive environments, a protective coating is often applied to provide moisture, dust, and corrosion resistance, improving the product's environmental adaptability. Automated and Intelligent Production Lines: Modern PCBA production is highly automated, with machines handling everything from board loading, printing, placement, reflow soldering, to unloading and inspection. Combined with big data analysis and artificial intelligence, production lines can achieve self-optimization and fault prediction, significantly improving production efficiency and product consistency.   If your product require professional PCBA solutions,feel free to contact us for learning more. Look forward to exploring the endless possibilities of electronic manufacturing with you!

Base material: 1, FR-4: The most commonly used glass fiber reinforced epoxy resin laminate substrate. Good flame retardancy (FR=Flame Retardant). 2,Polyimide: Commonly used in flexible circuit boards or high-temperature applications, with good heat resistance. 3,CEM-1/CEM-3: Composite epoxy resin substrate (paper base/glass fiber cloth base), low cost, and inferior performance to FR-4. 4,Aluminum substrate: Metal-based circuit board with aluminum as the base layer, used for LED lights with high heat dissipation requirements, etc. 5,Copper substrate: Metal-based circuit board with copper as the base layer, excellent heat dissipation performance, used for high-power devices. 6,Ceramic substrate: Alumina, aluminum nitride, etc., used for extremely high frequency, high temperature or high reliability applications. 7,Copper clad laminate: A sheet with copper foil on one or both sides of an insulating substrate, which is the raw material for manufacturing PCBs. Copper foil: 1,Electrolytic copper foil: Copper foil made by electrolytic deposition. 2,Rolled copper foil: Copper foil made by rolling process, with better ductility, often used in flexible boards. 3,Ounces: Common units of copper foil thickness, indicating weight per square foot of area (such as 1oz = 35μm). Laminates: 1,Core board: The base material layer inside a multilayer board (usually FR-4 with copper cladding on both sides). 2,Prepreg: Glass fiber cloth impregnated with resin, not fully cured. It melts, flows and solidifies after being heated and pressed during the lamination process, bonding the layers together. Conductive layer: Conductive pattern formed by etching copper foil, including wires, pads, copper cladding areas, etc. Insulating layer: Insulating medium between the substrate and each layer (such as FR-4, prepreg, solder mask, etc.). Welcome to contact with us www.suntekgroup.net

Key Technologies in PCB Assembly The complexity of PCB assembly lies in its integrated application of various technologies: Surface Mount Technology (SMT): This is the dominant technology in modern PCBA production. SMT utilizes high-precision equipment to directly solder tiny surface mount devices (SMDs) onto the PCB surface, significantly increasing assembly density and production efficiency. From chip resistors to complex BGA package chips, SMT handles them all efficiently. Its core stages include: Solder Paste Printing: Using a precise stencil to accurately print solder paste onto the pads. Component Placement: High-speed pick-and-place machines precisely position tens of thousands of components in their designated locations. Reflow Soldering: Through precisely controlled temperature profiles, the solder paste melts and solidifies, forming reliable solder joints.   Through-Hole Technology (THT): While SMT is dominant, THT remains indispensable for some components requiring greater mechanical stress resistance or higher heat dissipation (e.g., large capacitors, connectors). Component leads pass through holes on the PCB and are secured by wave soldering or manual soldering.   Soldering Techniques: Whether it's reflow soldering, wave soldering, selective wave soldering, or even manual soldering, solder joint quality is the bedrock of PCBA reliability. Precise temperature control, high-quality solder, and professional soldering skills ensure every joint is robust and reliable.   Testing and Inspection: Strict inspections are conducted at various stages of assembly to ensure product quality. This includes: AOI (Automated Optical Inspection): Uses optical principles to check component placement, soldering defects, etc. X-Ray Inspection: Used to check solder joint quality for hidden packages like BGAs and QFNs, which are not visible to the naked eye. ICT (In-Circuit Test): Uses probes to contact test points on the circuit board, checking circuit continuity and component electrical performance. Functional Test (FCT): Simulates the product's actual working environment to verify if the PCBA's functions meet design requirements.   PCB assembly is an indispensable part of the electronic manufacturing chain, and its technological advancements directly impact the performance and cost of electronic products. With the rapid development of emerging technologies like 5G, IoT, artificial intelligence, and electric vehicles, even higher and more complex demands are being placed on PCBA. In the future, PCB assembly will continue to evolve towards smaller, thinner, faster, and more reliable solutions, while also prioritizing environmental protection and sustainability. Precise manufacturing processes, stringent quality control, and continuous technological innovation will collectively drive PCB assembly technology to new heights, connecting us to a smarter, more interconnected future.   Does your product require professional PCBA solutions? Learn more by contacting us, and we look forward to exploring the endless possibilities of electronic manufacturing with you!

In today's highly integrated era of electronic devices, BGA (Ball Grid Array Package) chips have been widely used in many fields due to their many advantages, such as high integration and good electrical performance. However, no technology is perfect, and BGA chips also have some disadvantages that may pose certain challenges in specific application scenarios, manufacturing, and maintenance processes. 1, High welding difficulty The packaging form of BGA chips determines that their soldering process is relatively complex. Unlike traditional pin packaged chips, BGA chips have a dense array of solder balls arranged at the bottom. When soldering it onto a printed circuit board (PCB), it is necessary to precisely control parameters such as soldering temperature, time, and pressure. Once these parameters deviate, it is easy to lead to poor welding. For example, excessive temperature may cause tin balls to melt excessively, resulting in short circuits; If the temperature is too low, it may cause the solder balls to not fully melt, resulting in virtual soldering and unstable electrical connections between the chip and PCB, which in turn affects the normal operation of the entire electronic device. Moreover, due to the small size and large quantity of solder balls, it is difficult to directly observe the welding quality with the naked eye after welding, often requiring the use of professional testing equipment such as X-ray testing equipment, which undoubtedly increases production and maintenance costs. 2, High maintenance costs and difficulty When BGA chips malfunction and need to be replaced, maintenance personnel face a huge challenge. Firstly, it is not easy to remove the faulty chip from the PCB board. Due to its strong welding, it is difficult for conventional manual tools to disassemble it intact, often requiring the use of specialized equipment such as a hot air gun, and caution should be taken during the disassembly process to avoid damaging other components or circuits on the PCB board. When re soldering new BGA chips, it is also necessary to strictly control the soldering parameters to ensure the soldering quality. In addition, as mentioned earlier, the inspection after welding also requires professional equipment, and this series of operations requires extremely high technical skills from maintenance personnel, resulting in a significant increase in maintenance costs. In some cases, even experienced maintenance personnel may not be able to guarantee a 100% repair success rate due to the complexity of BGA chip maintenance, which may lead to the risk of the entire electronic device being scrapped due to chip failure, further increasing the economic losses of users. 3, Relatively limited heat dissipation performance Although BGA chips also consider heat dissipation in their design, their heat dissipation performance still has certain limitations compared to some other packaging forms of chips. The packaging structure of BGA chips is relatively compact, and heat is mainly conducted to the PCB board through the solder balls at the bottom of the chip for dissipation. However, the thermal conductivity of solder balls is limited. When the chip generates a large amount of heat under high load operation, the heat cannot be effectively dissipated in a timely manner, resulting in an increase in the internal temperature of the chip. Excessive temperature not only affects the performance of chips, slowing down their operation speed and causing data processing errors, but long-term exposure to high temperatures may also shorten the lifespan of chips and even cause permanent damage, thereby affecting the reliability and stability of the entire electronic device. 4, Relatively high cost The manufacturing process of BGA chips is relatively complex, involving multiple high-precision processes such as photolithography, etching, and packaging. These complex processes require the use of advanced production equipment and high-purity raw materials, which makes the manufacturing cost of BGA chips relatively high. Moreover, due to its unique packaging form, more caution is required during transportation and storage to prevent damage such as compression and collision to the chips, which also increases logistics and warehousing costs to a certain extent. For electronic device manufacturers, higher chip costs can compress the profit margins of their products, or they may have to pass on these costs to consumers, resulting in relatively high product prices and potentially affecting their competitiveness in the market. In summary, although BGA chips have an important position and wide applications in the field of modern electronic technology, we cannot ignore their disadvantages. In practical applications, electronic engineers and manufacturers need to fully consider these disadvantages and take corresponding measures to overcome or mitigate their impacts as much as possible, in order to ensure the performance, reliability, and economy of electronic devices. Any PCB-PCBA projects,warm welcome to email us sales9@suntekgroup.net.

IPC Class 2 vs. Class 3: What's the Difference? In the electronic interconnection industry, IPC stands for the global trade association. The primary goal of the IPC Class is to standardize the assembly, production process, and requirements of electronic components. In 1957, it was established under the Institute of Printed Circuits, which was later changed into the Institute for Interconnecting and Packaging Electronic Circuits. The organizations publish the specifications and requirements regularly. The IPC standard is one of the most accepted protocols in the electronic industry. This IPC standard helps design and fabricate reliable, safe, high-quality PCB products. We always talk about IPC Class 2 vs Class 3. What are the main differences between them in PCB manufacturing services? Generally speaking, IPC Class 2 is the normal standard for most electronics, such as consumer electronics, industrial equipment, medical equipment, communication electronics, power and control, transportation, computers, testing, etc, while Class 3 is required for more electronics needed more reliability, such as automotive, militarily, marine aerospace, etc.   Voids in PTH-Copper Plating Class 3–PCB Manufacturing Class 2–PCB Manufacturing PTH holes are plated perfectly. No void in the PTH hole at all. Max. 1 void in 1 PTH hole. The void should be small. Void less than 5% of the PTH hole size. Max. 5% holes with voids. The void is less than 90 degrees from the drill.   Voids in PTH – Finished Coating Class 3–PCB Manufacturing Class 2–PCB Manufacturing No void at all. Max. 1 void in 1 hole. Max. 5% holes with voids can be seen. The void length is less than 5% of the hole. The biggest void length is less than 5% Max. 3 voids all in one hole. Max. 15% holes with voids can be seen. The void length is less than 10% of the hole. The biggest void length is less than 5%   Etched Marking (components notation) Class 3–PCB Manufacturing Class 2–PCB Manufacturing Etched marks are clear Etched marks are a little blurry, but they can be recognized. Etched marks have no affection for other copper traces. Etched marks are not clear, but they can be recognized. If there is any part missing, not exceed 50% of the character. Etched marks have no affection for other copper traces.   Soda Strawing (the gap between the solder mask and base material) Class 3–PCB Manufacturing Class 2–PCB Manufacturing The solder mask connected with the base material is in good condition. There is no gap between the solder mask and the base material. The copper width remains the same. Copper trace is covered by a solder mask, and no solder mask peels off.   Conductor (copper trace) Spacing Class 3–PCB Manufacturing Class 2–PCB Manufacturing Copper trace width is the same as the design. Extra copper is less than 20% of the total copper trace width. Max. extra copper is less than 30% of the total copper trace width.   Out Layer Annular Ring-Supported Holes Class 3–PCB Manufacturing Class 2–PCB Manufacturing Holes in the center of the pads. The minimum ring size is 0.05mm. No ring breakout. Ring breakout less than 90 degrees.   Out Layer Annular Ring-Unsupported Holes Class 3–PCB Manufacturing Class 2–PCB Manufacturing Drill in the centre of the pads. The minimum ring size is 0.15mm. No ring breakout. Ring breakout is less than 90 degrees.   Surface Conductor Thickness (base and plating) Class 3–PCB Manufacturing Class 2–PCB Manufacturing Min. Copper plating is 20um. Min. Copper plating is 25 um.   Wicking (plating residue) Class 3–PCB Manufacturing Class 2–PCB Manufacturing No wicking (plating residue) when we make cross sections. If there is any wicking, the max. The size is 80um. No wicking (plating residue) when we make cross sections. If there is any wicking, the max. The size is 100um.   Solder Residue Class 3–PCB Manufacturing Class 2–PCB Manufacturing Max. Solder residue under the cover is 0.1mm. No solder wicking (residue) at the bendable parts. No effect on the copper trace or function. Max. Solder residue under the cover is 0.3mm. No solder wicking (residue) at the bendable parts. No effect on the copper trace or function.     For more please visit www.suntekgroup.net PCB, PCBA, Cables, Box-build

When selecting a PCBA (printed circuit board assembly) fabrication service provider, a number of factors need to be considered to ensure product quality, production efficiency, cost control, and service reliability. Below are some specific recommendations for selection:   I. Qualification and Certification Check the certification status: Ensure that the PCBA processing service provider has the necessary industry qualifications and certifications, such as ISO 9001 quality management system certification. These certifications not only represent the management level of the enterprise, but also reflect its emphasis on product quality. Examine the production experience: Understand the company's production history and success stories, and choose a service provider with rich experience and good reputation.   II. Technical capacity and equipment Technical strength: assess the technical capability of the enterprise, including the technical level of its R&D team, its process innovation ability and its ability to solve complex problems.   Production equipment: Understand the production equipment of the enterprise, including the advancement, stability and production efficiency of the equipment. Advanced equipment tends to provide higher quality processing services.   The glimps of Suntek China PCBA factory   The glimps of BLSuntek Cambodia  PCBA factory   Third, the quality management system Quality control process: Understand the quality control process of the enterprise, including raw material inspection, production process control, finished product testing and other links. Ensure that enterprises have strict quality control measures to ensure product quality.   Quality feedback mechanism: examine whether the enterprise has established a perfect quality feedback mechanism, in order to timely identify and solve the quality problems in the production process.   IV. Delivery time and production capacity Delivery time: Understand the company's delivery cycle and ability to provide emergency expedited services. In the design and production of electronic products, time is often very valuable, so you need to choose a service provider that can respond quickly and deliver on time. Production capacity: Evaluate whether the company's production capacity can meet your needs. Find out if the company's production line is flexible enough to accommodate different batches and specifications.   V. Cost and Price Cost structure: Understand the cost structure and expense composition of the enterprise in order to better assess the reasonableness of its offer. Price competitiveness: Compare the quotations of different PCBA processing service providers and choose the cost-effective enterprise. However, it should be noted that price should not be the only determining factor, and other factors need to be considered comprehensively.   Six, after-sales service and support After-sales service system: understand whether the enterprise's after-sales service system is perfect, including technical support, troubleshooting, maintenance and other aspects. Customer feedback: Check the customer feedback and cases of the enterprise to understand its service quality and customer satisfaction.   Seven, field visits and communication Site visit: If conditions permit, you can visit the production facilities and management of PCBA processing service providers, in order to more intuitively understand its production capacity and management level. Smooth communication: to ensure smooth and unimpeded communication with the enterprise, and be able to respond to your needs and questions in a timely manner.   To summarize, choosing a PCBA processing service provider is a process that requires comprehensive consideration of several factors. By carefully evaluating the enterprise's qualification, technology, quality, delivery, cost and after-sales service, you can choose the service provider that best suits your needs.   For more please visit www.suntekgroup.net PCB, PCBA, Cables, Box-build

Happy 13th Anniversary, Suntek Family!  April 16th 2025 marks a special milestone in our journey—13 years of passion, growth, and groundbreaking achievements. To honor this occasion, we embarked on an unforgettable team-building adventure, celebrating the bonds that make us unstoppable!   A Heartfelt Thank You: To every colleagues, partners, and clients—YOU are the reason we thrive. Your dedication fuels our mission to become a reliable and one-stop EMS factory in China.   Looking Ahead: The next chapter is bright! With new projects and a team stronger than ever, we’re ready to redefine the future.   Cheers to 13 Years—and Many More to Come!  Let’s keep innovating, inspiring, and growing TOGETHER.

On Nov 12th to 15th 2024,Suntek attended Electronica show in Munich Germany. Electronica is the most important,professional and famous show about electronics in the world.   We have gained much business opportunities and met many cooperated clients on this show. It is really a very successful show !

Israel customer visit our factory and audit PCB Assembly quality control on 21st Oct.   First of all,Thank you very much for your visit to our company this time, including factory scale, storage, wiring harness workshop, SMT production line, THT production line, AOI,ICT,X-RAY,FT, etc. During the visit, our company introduced in detail how to control product quality in each link. The customer is very satisfied with our production process and quality control. It has laid a solid foundation for the later cooperation, and we look forward to further cooperation.

Suntek is a contract factory on PCB assembly,wire harness and box-build in China and in Cambodia.we are glad to announce that we will attend the Electronica 2024 which is held in Munich,Germany on November 12~15, 2024.We will exhibit the latest products which are widely used in industrial,IOT,5G,medical,auto...fields and these products will reflect our strong capability and advantage in assembly of Mini BGAs,0201 component,conformal coating and press-fit.we hereby sincerely invite you to visit our booth in Hall#C6 230/1,looking forward to meeting you there!   Exhibition name:Electronica 2024 (in Munich) Address: Trade Fair Center Messe München Booth number: C6.230/1 Date: Nov 12th to Nov 15th 2024 Opening hours:Tue. to Thur.:09:00–18:00 Fri.:09:00–15:00   Thank you!

In-circuit testing (ICT) is a performance and quality testing method for printed circuit boards (PCB). While there are many types of PCB testing, ICT covers essential testing capacities to help manufacturers determine whether their components and units function and meet the product specifications and capabilities. Understanding what in-circuit testing is, what it covers and its strengths can help you determine if it will handle testing your PCBs. Basic Overview of ICT ICT offers basic PBC testing for various manufacturing errors and electrical functions. While many manufacturers include highly skilled personnel and automated equipment, testing can help locate critical errors that maintain unit function and quality. This testing method combines custom-designed hardware with specifically programmed software to create highly specialized testing that works only for one PCB type. ICT will test components individually, checking that each one is in the right place and meets the product and industry capacity and functionality. This testing method is an excellent way of ensuring that everything is where it needs to be, especially as units grow smaller. While ICT can give you an idea of functionality, this is only for logic functionality. ICT involves testing each component in your unit individually to ensure they all function, allowing in-circuit testing methods to give manufacturers and engineers an idea of how units will function together. Primary Types of ICT When considering using a specific type of circuit testing like ICT, you will need to understand its particular processes and the kinds of tests it runs: Component placement and implementation: Because engineers will design your ICT hardware specifically for your PCBs, the hardware will connect with specific test points to link with specific components and assess their function. As they do this, they can also ensure that all components are in the right space and that your PCBs include all the right components. After these tests, you will know that all the right components are in the right spaces. Circuitry: As PCBs grow smaller, there is less space for circuits and components, causing engineers and manufacturers to create complex and tight units. Using ICT allows your teams to search for open or short circuits on each unit. Component condition: While testing that your unit has every component it needs in the right spaces, you will want to ensure that each component is of the highest quality. ICT can screen for damaged or low-functioning components, providing you with a way to control your component and unit quality. Electrical functionality: ICT provides a wide range of electrical functions, including resistance and capacitance. Your testing equipment will run specific currents through the components to see if they meet your determined standards. Knowing how ICT works can help you determine if it is a good option for your PCBs. You can experience comprehensive quality and function testing with ICT because of the range of testing it offers. Hardware and Software Used in the ICT Process Like all testing equipment, ICT uses specific tools and equipment to function. Learning what hardware and software make up this testing process can help engineers and manufacturers better understand in-circuit testing techniques and what makes this testing method unique. The Nodes ICT hardware includes a set of test points that you can use to connect with various compartments, which many engineers and manufacturers describe as a bed of nails because of the density of contact points. Because they contact the PCB and its components individually, they are the hardware that measures the different requirements for each test. To reach your PCB’s components in their unique configuration, engineers and manufacturers will need to arrange the nodes to meet the test points. This means that every PCB type will require a specific node arrangement so it can contact the components. If you manufacture and test multiple PCBs, you will need to invest in several in-circuit testers. The Software While hardware will carry out the testing, software will help direct the hardware and store vital information about your PCB and its components. It will prompt nodes to contact their component, begin running tests and collect data about their performance and placement. Just as your nodes need customization before using them on your PCB, you will need someone to program your software to collect information specific to that unit. You use it to establish pass/fail parameters so it can determine whether components uphold standards.     Advantages of ICT ICT is an incredibly precise testing technique that allows engineers and manufacturers to produce the same results every time. However, you can experience more benefits beyond quality and reliability with ICT, including: Time and cost efficiency: Compared to other PCB testing methods, ICT is very quick. It can finish testing all components within a few minutes or less. When you spend less time testing each PCB, your testing processes will cost less. ICT provides manufacturers and engineers with a quick and cheaper way of testing that still offers consistent and accurate results. Mass testing: Manufacturers can use ICT to test large amounts of PCBs because of its high efficiency. ICT provides comprehensive quality testing. While it only tests individual components, you can still understand how your unit functions. Manufacturers who produce higher PCBs can test units quickly without compromising quality. Customization and updates: Your hardware and software will include designs specific for each PCB, allowing it to optimize your testing. When you use ICT, you will know that every test and piece of equipment you use is designed for that product to provide the most specific testing. Further, you can update standards and test through your software. Disadvantages of ICT While ICT can be an excellent option for many companies, understanding the challenges accompanying it is vital when determining its suitability for you and your products. Some disadvantages of ICT include: Upfront costs and development time: Because you will need to program and customize your ICT hardware and software to fit each PCB configuration, prices and development time can be higher. You will have to wait for engineers to create nodes that contact every component in your unit and program the software with your product’s standards and specifications. Individual testing: While ICT can provide more comprehensive testing, it can only test how each component functions independently. You will need to use alternative testing techniques to understand how your components work together or overall unit functionality.

Printed circuit board (PCB) is the core component of modern electronic devices, and its performance and quality largely depend on the board used. Different boards have different characteristics and are suitable for various application needs.   1. FR-4 1.1 Introduction FR-4 is the most common PCB substrate, made of glass fiber cloth and epoxy resin, with excellent mechanical strength and electrical performance.   1.2 Characteristics -Heat resistance: FR-4 material has high heat resistance and can usually work stably at 130-140 ° C. -Electrical performance: FR-4 has good insulation performance and dielectric constant, suitable for high-frequency circuits. -Mechanical strength: Glass fiber reinforcement gives it good mechanical strength and stability. -Cost effectiveness: Moderate price, widely used in consumer electronics and general industrial electronic products.   1.3 Application FR-4 is widely used in various electronic devices, such as computers, communication equipment, household appliances, and industrial control systems.   2. CEM-1 and CEM-3 2.1 Introduction CEM-1 and CEM-3 are low-cost PCB substrates mainly made of fiberglass paper and epoxy resin.   2.2 Characteristics -CEM-1: Single sided board with slightly lower mechanical strength and electrical performance than FR-4, but at a lower price. -CEM-3: Double sided board with performance between FR-4 and CEM-1, possessing good mechanical strength and heat resistance. 2.3 Application CEM-1 and CEM-3 are mainly used in low-cost consumer electronics and household appliances such as televisions, speakers, and toys.   3. High frequency boards (such as Rogers) 3.1 Introduction High frequency boards (such as Rogers materials) are specifically designed for high-frequency and high-speed applications, with excellent electrical performance. 3.2 Characteristics -Low dielectric constant: ensures stability and high speed of signal transmission. -Low dielectric loss: suitable for high-frequency and high-speed circuits, reducing signal loss. -Stability: Maintain stable electrical performance over a wide temperature range. 3.3 Application High frequency boards are widely used in high-frequency application fields such as communication equipment, radar systems, RF and microwave circuits.   4. Aluminum substrate 4.1 Introduction Aluminum substrate is a PCB substrate with good heat dissipation performance, commonly used in high-power electronic devices. 4.2 Characteristics -Excellent heat dissipation: Aluminum substrate has good thermal conductivity, which can effectively dissipate heat and extend the life of components. -Mechanical strength: Aluminum substrate provides strong mechanical support. -Stability: Maintaining stable performance in high temperature and high humidity environments. 4.3 Application Aluminum substrates are mainly used in fields such as LED lighting, power modules, and automotive electronics that require high heat dissipation performance.   5. Flexible sheets (such as Polyimide) 5.1 Introduction Flexible sheets, such as polyimide, have good flexibility and heat resistance, making them suitable for complex 3D wiring 5.2 Characteristics -Flexibility: Flexible and foldable, suitable for small and irregular spaces. -Heat resistance: Polyimide materials have high heat resistance and can work in high temperature environments. -Lightweight: Flexible boards are lightweight and help reduce equipment weight. 5.3 Application Flexible sheets are widely used in applications that require high flexibility and lightweight, such as wearable devices, mobile phones, cameras, printers, and aerospace equipment.   6. Ceramic substrate 6.1 Introduction Ceramic substrates have excellent thermal conductivity and electrical properties, making them suitable for high-power and high-frequency applications. 6.2 Characteristics -High thermal conductivity: Excellent heat dissipation performance, suitable for high-power electronic devices. -Electrical performance: low dielectric constant and low loss, suitable for high-frequency applications. -High temperature resistance: Stable performance in high temperature environments. 6.3 Application Ceramic substrates are mainly used for high-frequency and high-power applications such as high-power LEDs, power modules, RF and microwave circuits.   Conclusion Choosing the appropriate PCB board is the key to ensuring the performance and reliability of electronic devices. FR-4, CEM-1, CEM-3, Rogers materials, aluminum substrates, flexible sheets, and ceramic substrates each have their own advantages, disadvantages, and applicable fields. In practical applications, the most suitable board should be selected based on specific needs and working environment to achieve optimal performance and cost-effectiveness.

In the field of electronic manufacturing, SMT surface mount processing and DIP plug-in processing are two common assembly processes. Although they are all used to mount electronic components onto circuit boards, there are significant differences in the process flow, types of components used, and application scenarios.   1. Differences in process principles SMT Surface Mount Technology: SMT is the process of accurately placing surface mount components (SMD) onto the surface of a circuit board using automated equipment, and then fixing the components onto a printed circuit board (PCB) through reflow soldering. This process does not require drilling holes on the circuit board, so it can more effectively utilize the surface area of the circuit board and is suitable for high-density, high integration circuit designs. DIP plugin processing (Dual Inline Package): DIP is the process of inserting the pins of a component into pre drilled holes on a circuit board, and then fixing the component using wave soldering or manual soldering. DIP technology is mainly used for larger or higher power components, which typically require stronger mechanical connections and better heat dissipation capabilities. 2. Differences in the use of electronic components SMT surface mount processing uses surface mount components (SMD), which are small in size and light in weight, and can be directly mounted on the surface of circuit boards. Common SMT components include resistors, capacitors, diodes, transistors, and integrated circuits (ICs). DIP plug-in processing uses plug-in components, which usually have longer pins that need to be inserted into holes on the circuit board before soldering. Typical DIP components include high-power transistors, electrolytic capacitors, relays, and some large ICs.   3. Different application scenarios SMT surface mount processing is widely used in the production of modern electronic products, especially for equipment that requires high-density integrated circuits, such as smartphones, tablets, laptops, and various portable electronic devices. Due to its ability to achieve automated production and save space, SMT technology has significant cost advantages in mass production. DIP plug-in processing is more commonly used in scenarios with higher power requirements or stronger mechanical connections, such as industrial equipment, automotive electronics, audio equipment, and power modules. Due to the high mechanical strength of DIP components on circuit boards, they are suitable for environments with high vibration or applications that require high heat dissipation.   4. Differences in process advantages and disadvantages The advantages of SMT surface mount processing are that it can significantly improve production efficiency, increase component density, and make circuit board design more flexible. However, the disadvantages are high equipment requirements and difficulty in manual repair during the processing. The advantage of DIP plug-in processing lies in its high mechanical connection strength, which is suitable for components with high power and heat dissipation requirements. However, the disadvantage is that the process speed is slow, it occupies a large PCB area, and is not suitable for miniaturization design. SMT surface mount processing and DIP plug-in processing each have their unique advantages and application scenarios. With the development of electronic products towards high integration and miniaturization, the application of SMT surface mount processing is becoming increasingly widespread. However, in some special applications, DIP plug-in processing still plays an irreplaceable role. In actual production, the most suitable process is often selected based on the needs of the product to ensure the quality and performance of the product.

Welding is one of the most critical steps in PCBA processing. Different types of electronic components have different characteristics and requirements during soldering, and a slight carelessness may lead to soldering quality issues, affecting the performance and reliability of the final product. Therefore, understanding and following the welding precautions for various components is crucial to ensuring the quality of PCBA processing. This article will provide a detailed introduction to common electronic component soldering precautions in PCBA processing.   1. Surface mount components (SMD) Surface mount components (SMD) are the most common type of electronic components in modern products. They are directly installed on the surface of the PCB through reflow soldering technology. The following are the main precautions for SMD soldering: a. Accurate component alignment It is crucial to ensure precise alignment between components and PCB pads during SMD soldering. Even small deviations can lead to poor soldering, which in turn can affect circuit functionality. Therefore, it is very important to use high-precision surface mount machines and alignment systems. b. Appropriate amount of solder paste Excessive or insufficient solder paste can affect the quality of soldering. Excessive solder paste may lead to bridging or short circuits, while insufficient solder paste may result in poor solder joints. Therefore, when printing solder paste, the appropriate thickness of the steel mesh should be selected according to the size of the components and solder pads to ensure precise application of the solder paste. c. Control of Reflow Soldering Curve The setting of reflow soldering temperature curve should be optimized according to the material characteristics of the components and PCB. The heating rate, peak temperature, and cooling rate all need to be strictly controlled to avoid component damage or welding defects.   2. Dual in-line package (DIP) components Dual in-line package (DIP) components are soldered by inserting them into through holes on the PCB, usually using wave soldering or manual soldering methods. The precautions for DIP component soldering include: a. Control of insertion depth The pins of DIP components must be fully inserted into the through holes of the PCB, with consistent insertion depth, to avoid situations where the pins are suspended or not fully inserted. Incomplete insertion of pins may result in poor contact or virtual soldering. b. Temperature control of wave soldering During wave soldering, the soldering temperature should be adjusted based on the melting point of the solder alloy and the thermal sensitivity of the PCB. Excessive temperature may cause PCB deformation or component damage, while low temperature may lead to poor solder joints. c. Cleaning after welding After wave soldering, the PCB must be cleaned to remove residual flux and avoid long-term corrosion of the circuit or affecting insulation performance.   3. Connectors Connectors are common components in PCBA, and their soldering quality directly affects the transmission of signals and the reliability of connections. When welding connectors, the following points should be noted: a. Control of welding time The pins of connectors are usually thicker, and prolonged soldering time may cause overheating of the pins, which can damage the plastic structure inside the connector or lead to poor contact. Therefore, the welding time should be as short as possible, while ensuring that the welding points are fully melted. b. The use of soldering flux The selection and usage of soldering flux should be appropriate. Excessive soldering flux may remain inside the connector after soldering, affecting the electrical performance and reliability of the connector. c. Inspection after welding After welding the connector, strict inspection is required, including the quality of the solder joints on the pins and the alignment between the connector and the PCB. If necessary, a plug and unplug test should be conducted to ensure the reliability of the connector. 4. Capacitors and resistors Capacitors and resistors are the most basic components in PCBA, and there are also some precautions to be taken when soldering them: a. Polarity recognition For polarized components such as electrolytic capacitors, special attention should be paid to polarity labeling during welding to avoid reverse welding. Reverse welding can cause component failure and even lead to circuit faults. b. Welding temperature and time Due to the high sensitivity of capacitors, especially ceramic capacitors, to temperature, strict control of temperature and time should be exercised during welding to avoid damage or failure of capacitors caused by overheating. Generally speaking, the welding temperature should be controlled within 250 ℃, and the welding time should not exceed 5 seconds. c. Smoothness of solder joints The solder joints of capacitors and resistors should be smooth, rounded, and free from virtual soldering or solder leakage. The quality of solder joints directly affects the reliability of component connections, and insufficient smoothness of solder joints may lead to poor contact or unstable electrical performance.   5. IC chip The pins of IC chips are usually densely packed, requiring special processes and equipment for soldering. The following are the main precautions for soldering IC chips: a. Optimization of Welding Temperature Curve When soldering IC chips, especially in packaging forms such as BGA (Ball Grid Array), the reflow soldering temperature curve must be precisely optimized. Excessive temperature may damage the internal structure of the chip, while insufficient temperature may result in incomplete melting of solder balls. b. Prevent pin bridging The pins of IC chips are dense and prone to solder bridging problems. Therefore, during the welding process, the amount of solder should be controlled and the surface mount process of solder bridges should be used. At the same time, X-ray inspection is required after welding to ensure welding quality. c. Static protection IC chips are highly sensitive to static electricity. Before and during soldering, operators should wear anti-static wristbands and operate in an anti-static environment to prevent damage to the chip from static electricity.   6. Transformers and inductors Transformers and inductors mainly play the role of electromagnetic conversion and filtering in PCBA, and their soldering also has special requirements: a. Welding firmness The pins of transformers and inductors are relatively thick, so it is necessary to ensure that the solder joints are firm during welding to avoid loosening or breaking of the pins due to vibration or mechanical stress during subsequent use. b. The fullness of solder joints Due to the thicker pins of transformers and inductors, the solder joints should be full to ensure good conductivity and mechanical strength. c. Magnetic core temperature control The magnetic cores of transformers and inductors are temperature sensitive, and overheating of the cores should be avoided during welding, especially during long-term welding or repair welding.   The welding quality in PCBA processing is directly related to the performance and reliability of the final product. Different types of components have different requirements for welding processes. Strictly following these welding precautions can effectively avoid welding defects and improve the overall quality of the product. For PCBA processing enterprises, improving the level of welding technology and strengthening quality control are the key to ensuring product competitiveness.

From January 27th to 29th, 2024, the CTO of the Israeli company and the software engineer of Bulgaria came to our company for PCBA sample testing and certification of the new project and factory inspection. Suntek Group is a professional supplier in EMS field with one-stop solution for PCB ,PCB assembly ,cable assembly,Mix. Technology assembly and box-building. With ISO9001:2015,ISO13485:2016,IATF 16949:2016 and UL E476377 certified.We deliver qualified products with competitive price to clients all over the world. Mr. Lau introduced the performance and daily use of BGA optical inspection equipment X-RAY. Our customer representatives view the SMT back-end work site (AOI, DIP wave soldering workshop, functional test pull, QA, packaging, etc.) This sample project is a total of 8 types. With the full cooperation of our marketing, engineering, quality inspection, production, PMC and other departments, the sample testing work is very successful. The customer has a very high evaluation of our team, which has laid a solid foundation for our long-term cooperation.
