Name: IoT Smart Home PCBA Wi-Fi BLE Module ESP32 4-Layer Control Board Assembly Service
Brand: Suntek Electronics Co., Ltd.
SKU: SUN-IOT-4L
Price: 16.00 USD
Availability: InStock

Home > products > EMS PCBA >

IoT Smart Home PCBA Wi-Fi BLE Module ESP32 4-Layer Control Board Assembly Service

IoT Smart Home PCBA

Wi-Fi BLE Module Assembly

ESP32 Control Board PCBA

Place of Origin:

China/Cambodia

Brand Name:

Suntek

Certification:

ISO9001, ISO13485, IATF16949, UL

Model Number:

SUN-IOT-4L

Request A Quote

Product Details

Wireless Modules:

ESP32, ESP8266, Wi-Fi 6, BLE 5.0, Zigbee, LoRa

Layer Count:

4 Layers (2-8 Layers Available)

Antenna Handling:

Keep-out Zone, Matching Network, RF Shield Can

Min Package:

0201

Board Thickness:

0.8mm-1.6mm

Surface Finish:

ENIG, HASL Lead-free

Connectivity Test:

Wi-Fi Throughput, BLE Pairing, Antenna Return Loss

Firmware:

OTA Provisioning Support

Payment & Shipping Terms

Minimum Order Quantity

1 Piece

Price

USD 4-28 / Piece

Packaging Details

ESD bag, anti-static tray, moisture barrier bag, export carton

Delivery Time

3-5 working days for prototype, 12-18 working days for batch

Payment Terms

T/T,L/C,PayPal,Western Union

Supply Ability

60000 Pieces per Month

Conformal Coated Potting PCBA IP67 Waterproof Outdoor Control Board Protection Service

Get Best Price

Video

IC Programming Functional Test PCBA 100% ICT FCT Testing Service 32-Layer Board Assembly

Get Best Price

Video

IoT Smart Home PCBA Wi-Fi BLE Module ESP32 4-Layer Control Board Assembly Service

Get Best Price

Video

Industrial Control PCBA 4-Layer Board -40C to 85C Wide Temperature Assembly Service

Get Best Price

0086-731-84874736

Contact Now

Product Description

IoT Smart Home PCBA Assembly

Smart home products live or die on radio performance. This 4-layer PCBA service is built around ESP32 class wireless modules, with antenna keep-out zones respected, matching networks tuned, and RF shielding applied where the enclosure demands it. The result is a board that passes certification without a redesign loop.

Board and module capability

Item	Capability
Wireless platforms	ESP32, ESP8266, Wi-Fi 6, BLE 5.0, Zigbee, LoRa
Layer count	4 layers standard, 2 to 8 layers available
Min package	0201, fine pitch 0.25mm
Antenna control	Keep-out zone, pi matching network, shield can placement
Surface finish	ENIG, HASL lead-free
Board thickness	0.8mm-1.6mm

RF and functional testing

Wi-Fi throughput and BLE pairing test at the fixture
Antenna return loss check on sample units from each lot
Current profile verification in active, idle and deep sleep modes
OTA provisioning and MAC address logging for traceability

Typical products

Smart switches, thermostat controllers, smart locks, air quality monitors, robot vacuum main boards, smart lighting drivers and gateway modules.

Ordering information

Share Gerber, BOM, module datasheet and antenna placement constraints. We will flag RF layout risks before tooling. Prototype orders from one piece; NDA available.
