5G Communication RF PCBA Rogers 4350B 8-Layer Board Impedance Control 0.2mm Trace

5G Communication RF PCBA on Rogers 4350B

This 8-layer RF PCBA is engineered for 5G base station, small cell and microwave backhaul hardware. Rogers 4350B laminates keep insertion loss low across the 3.5GHz and 28GHz bands, while controlled impedance routing holds signal integrity from the radio front end to the antenna port.

Build specification

Why this RF PCBA

• Low-loss Rogers 4350B stack-up tuned for 5G sub-6GHz and mmWave boards
• Impedance coupons on every panel with TDR report supplied
• Mixed material stack-up supported when RF and digital layers share one board
• Stiffener and shielding frame assembly available on request

Quality system

Assembled under IPC-A-610 Class 2 or Class 3, with IQC, IPQC, FQC and OQC gates. Facilities hold ISO9001, ISO13485, IATF16949 and UL certification, and both China and Cambodia production lines are available for tariff planning.

Ordering information

Send Gerber, BOM, pick-and-place file and stack-up requirements for a quote within 12 hours. Prototype orders start from one piece, and NDA can be signed before files are shared.
