Suntek is a leading EMS supplier based in Changsha, China, with over 10 years of experience in PCB assembly and cable assembly. Certified with ISO 9001:2015, ISO13485, IATF16949, and UL, we deliver qualified products at competitive prices to clients worldwide.
Product Description
Our SMT Electronic Circuit Assembly delivers precision Surface Mount Technology with an assembly tolerance of ±0.1mm. Supporting electronic component assembly for diverse applications, this service ensures accurate placement and reliable soldering for high-quality PCB production.
Manufactured on ISO-certified SMT and DIP production lines, the board supports 1-22 layers with multiple surface finish options. A 1-year warranty and rapid lead time with stocked components ensure dependable delivery.
Features
- Assembly Tolerance: ±0.1 mm
- Assembly Type: Surface Mount Technology
- Surface Finish: HASL, ENIG, OSP, Immersion Tin
- Layout Layers: 1-22 Layer
- Min Space: 0.1MM / 4Mil
- 1-year Guarantee
Technical Parameters
| Solder Mask | Green, Blue, Black, Red, White, Matt Color |
| Surface Finish | HASL, ENIG, OSP, Hard Plating, Immersion Tin |
| Soldermask | Green |
| Assembly Type | Surface Mount Technology |
| Silk Screen | White |
| Min Space | 0.1MM / 4Mil |
| Layers | 6 Layers |
| Features | 100% E-test |
| Guarantee | 1-year |
| Lead Time | With Stocks |
The Suntek product (Origin: China/Cambodia) is designed for telecommunications, automotive electronics, consumer devices, and industrial control systems. With 1-22 layer support and 0.1mm minimum spacing, it delivers precise high-density PCB solutions for prototype development and mass production.
Compliant with IPC-6012D and manufactured on ISO-certified lines, this assembly ensures consistent electrical performance and mechanical stability for safety-critical applications.
Customization
Suntek offers professional customization based on your Gerber or CAD design files. Options include multiple soldermask colors, surface finishes, and layer configurations for compact, efficient PCB designs.
Support and Services
Our dedicated technical team provides comprehensive support including design consultation, assembly process optimization, post-production testing, and troubleshooting.
Packing and Shipping
All assemblies are packaged in anti-static bags with cushioning materials in sturdy boxes. Packages are clearly labeled with handling instructions and tracking information.
FAQ
Q1: Brand?
A1: Suntek.
Q2: Origin?
A2: China and Cambodia.
Q3: Lead time?
A3: 7-15 business days.
Q4: Custom designs?
A4: Yes, Gerber and CAD formats.
Q5: Standards?
A5: IPC-6012D, ISO 9001:2015 certified.
