Name: High TG FR4 Medical PCB Assembly with ICT FT Testing and 1-32 Layers for Medical Applications
Brand: Suntek Electronics Co., Ltd.
SKU: F025-1213
Price: 49.10 USD
Availability: InStock

Home > Products > Medical PCB Assembly >

High TG FR4 Medical PCB Assembly with ICT FT Testing and 1-32 Layers for Medical Applications

High TG FR4 Medical PCB Assembly

ICT FT Testing PCBA

1-32 Layers Printed Circuit Board Assembly

Place of Origin:

China or Cambodia

Brand Name:

Suntek/BLSuntek

Certification:

ISO9001 ISO13485 IATF16949 UL

Model Number:

F025-1213

Request A Quote

Product Details

Material::

FR4(Tg130-Tg180)/Rogers/Aluminum

Solder Mask::

Green,Blue,Black,Red,White,Matt Color

Copper::

0.5OZ-10OZ

Layer::

1L-32L

SMT,THT::

Yes

Thickness::

1.0mm/1.6mm/2mm/4mm

RoHs::

Lead Or Lead Free

Warranty::

1year

Hole Min.::

0.1mm

Payment & Shipping Terms

Minimum Order Quantity

No Limited

Price

Customized products

Packaging Details

By ESD bags and carton

Delivery Time

5-7days after all components kitted

Payment Terms

T/T

ISO13485 Certified Turnkey Medical PCB Assembly PCBA Manufacturer with 32 Layer Capability

Get Best Price

Video

OEM / ODM Multilayer Medical PCB Assembly ROHS ISO13485 Certified

Get Best Price

Video

Medical PCB Assembly Turnkey PCBA Solution 100% E-test with IPC-A-610 Class 3 ISO13485 Certified

Get Best Price

Video

Pcb prototype fabrication services manufacturer with competitive price

Get Best Price

Contact Now

Product Description

High TG FR4 SMT Board Assembly Service with ICT & FT Testing

Suntek Group provides comprehensive contract manufacturing services in the EMS field, offering one-stop solutions for PCB/FPC assembly, cable assembly, and box-build assembly. Our facilities in Hunan Province, China and Kandal Province, Cambodia are ISO9001:2015, ISO13485:2016, IATF 16949:2016 and UL E476377 certified.

Manufacturing Capabilities

Specifications	Details
Material type	FR-1, FR-4, CEM-1, aluminum clad
Material thickness (mm)	0.4, 0.6, 0.8, 1.0, 1.2, 1.6, 2.0
Layer count	1 to 32 Layers
Max. Board size	23.00" x 35.00"(580mm*900mm)
IPC class	Class II, Class III, Class 1
Annular ring	5 mil/side or Greater (Min. Design)
Finish plating	Solder(HASL), Lead Free Solder(HASL), ENIG, OSP, immersion silver, immersion tin, immersion nickel, hard gold, other
Copper weight	0.5OZ-10OZ
Trace/space width	3 Mils or greater
Drill clearance	0.1mm(laser drilling)
Plated slots	0.036 or greater
Smallest hole (finished)	0.1mm or greater
Gold fingers	1 to 4 Edge (30 to 50 Micron Gold)
SMD pitch	0.080" - 0.020" - 0.010"
Solder mask type	LPI Glossy, LPI-Matte, SR1000
Solder mask color	Green, red, blue, black, white, yellow
Legend color	White, yellow, black, red, blue
CNC route point	Any
Minimum route width	0.031"
Scoring	Straight lines, jump scoring, panel edge to edge, CNC*
Body gold	HARD, IMMERSION (up to 50 MICRON GOLD)
Data file format	Gerber 274x with embedder aperture
FAB. Drawing format	DXF, HPGL, DWG, PDF, Gerber
E.T testing	Flying probe, single sided, 1up plate, clamp shell, net list
Counter sink/counter bore	Available up to 0.250 Diameter
Control impedance	Yes
Blind vias/buried vias	Yes
Peelable mask	Yes
Carbon	Yes

Applications

Comprehensive Manufacturing Solutions

PCB/FPC fabrication
Components sourcing
PCB/FPC assembly
Custom cable/harness assembly
Box build assembly

Detailed Assembly Services

SMT, THT, BGA, 0201 Chips assembly
AOI, X-Ray, ICT, FT, Burn-in testing
Conformal coating or gluing
High-mix, small to medium volume production

EMS Manufacturing Advantages

Strict product liability following IPC-A-610 standards

Fluent English-speaking teams

PDCA management tool implementation

100% E-test and visual inspection (IQC, IPQC, FQC, OQC)

Comprehensive AOI inspection including X-ray, 3D microscope and ICT

High-voltage test and impedance control test

ISO9001, ISO13485, IATF16949 and UL certified

No minimum order quantity requirements

Specialized in low to medium volume production

Quick and reliable on-time delivery

Why Choose Suntek?

As an experienced and reliable manufacturer, Suntek provides one-stop service including PCB manufacturing and assembly for global customers with diverse project requirements. Our strong technical teams help customers save time and money while delivering the highest quality products at competitive prices.

Instant Quote

Receive our instant quote within 24-48 hours with positive feedback on all project specifications.

Strong Technical Team

Our professional engineers provide technical support from PCB design to turnkey assembly, answering all questions promptly throughout the process.

Advanced Equipment

State-of-the-art automated equipment ensures high efficiency, cost-effectiveness, and timely delivery of quality boards.

After Sales Service

We track all orders and provide instant updates throughout the manufacturing process with dedicated customer service representatives.

Customer Support & Quality Assurance

We ensure complete cost transparency with BOM cost breakdown sharing and source components from global suppliers.

Communication Procedures

Customer service procedure
RMA procedure
8D reports
PDCA (Plan-Do-Check-Action) in customer service

Response Commitment

Weekly progress reports
Dedicated customer support team
Customer satisfaction monitoring

After-Sales Services

1-year guarantee period for all products
Free-of-charge repair services
Quick replacement of defective parts

PCB Assembly Quality System

Quality Target

95% customer satisfaction rate

Quality Policy

Continuous improvement for perfect quality and win-win customer relationships.

Business Solution

One-stop, flexible, and continuously improving services.

Business Philosophy

Quality Wins Market, Ideas Create The Future.

Company Vision

Become long-term win-win partners in the EMS field.

PCBA Assembly Process Flow

Frequently Asked Questions

Q1: What files do you use in PCB fabrication?

A1: Gerber, PCB, and Auto CAD files.

Q2: How do you ensure product quality?

A2: All products undergo 100% E-testing. PCB assemblies include 100% AOI, ICT, FT and visual inspection, with 100% X-ray for BGA components.

Q3: Can we visit your company?

A3: Yes, we welcome visits to our facility located in Xingsha Industrial Park, Changsha, Hunan province, China.

Q4: What is the lead time?

A4: Sample orders: 3-5 working days; Batch production: 7-10 working days; PCB assembly: 15-20 working days.

Q5: Will you keep our information and files confidential?

A5: Yes, protecting customer designs and business secrets is our fundamental principle. NDA can be signed at any time.

Q6: How do we start working with you?

A6:

Email us your PCB layout file and BOM list
We confirm within 12 hours and provide quotes within 3-5 days
Confirm pricing, place order, and arrange payment terms
We proceed with manufacturing

We utilize advanced manufacturing equipment and technology, supported by professional engineering, purchasing, quality, and management teams to guarantee high-quality products and on-time delivery. Our products serve industrial control, automotive, telecommunications, medical equipment, consumer electronics, and other industries.
