Professional EMS PCBA Services with ISO UL Certification for Medical Equipment

Professional EMS PCBA Services With ISO UL Certification For Medical Equipment

About Suntek Group:

Suntek Group is a contract supplier in EMS field with one-stop solution for FCB/FPC assembly,Cable assembly,and Box-build assembly.

With ISO9001:2015,ISO13485:2016,IATF 16949:2016 and UL E476377 certified,

We deliver qualified products with competitive price to clients all over the world.

Product Features:

The Role of PCBA in Medical Equipment:
1. Enabling Circuit Connections and Specific Functions

PCBA serves as the carrier for electronic components, connecting various components precisely through conductive circuits on a printed circuit board (PCB) to form a complete circuit system.

In medical devices, this system can perform specific electronic functions according to design requirements, such as signal processing, power management, and data transmission.

For example, in imaging diagnostic devices (CT, MRI, ultrasound, etc.), the signal processing board of the PCBA must have high-speed data transmission capabilities while meeting low-noise and high-interference resistance requirements to perform signal processing functions.

2. Simplifying the Assembly Process of Medical Devices

Before the advent of PCBA, the assembly of medical devices often required manual soldering of numerous components and wires, which was not only inefficient but also prone to errors.

PCBA, however, utilizes automated surface mount technology to precisely place components on the PCB, significantly simplifying the assembly process and improving production efficiency.

Additionally, the modular design of PCBA makes the assembly of medical devices more convenient and efficient.

3. Enhancing the reliability and stability of medical devices

PCBA employs high-precision manufacturing processes and high-quality raw materials to ensure the stability and reliability of circuit connections. In medical devices, reliability requirements are extremely high, as any malfunction could pose a threat to patient safety.

Therefore, during the design and manufacturing process of PCBA, high-reliability components and processes must be used. Through reasonable layout and routing design, electromagnetic interference (EMI) and signal attenuation issues can also be effectively reduced, thereby enhancing the overall performance of medical devices and ensuring their stable operation.

4. Achieving high-density integration

PCBA enables high-density integration of components, allowing medical devices to become increasingly powerful while continuously reducing in size.

For example, portable blood glucose monitors and capsule endoscopes require PCBA to integrate hundreds of components within a space the size of a fingernail. This necessitates SMT production lines capable of mounting 01005 ultra-miniature components with positioning accuracy of ±0.025mm to meet the miniaturization demands of medical devices.

Packing and Shipping:

Medical PCB Assembly - Packaging and Shipping

Our Medical PCB Assembly products are carefully packaged and shipped to ensure their safe delivery to our customers. We understand the importance of maintaining the quality and integrity of our products, especially in the medical industry. That's why we follow strict packaging and shipping guidelines to ensure that our products arrive at their destination in perfect condition.

Our Advantages:

What Suntek Group Can Offer:

1. PCB and FPC bare board

2. PCB and FPC assembly

3. Components purchasing and materials customization

4. One-stop of turnkey box build assembly

5. Mixed technology mix assembly

6. Cable assembly and wire harness

7. Low/mid/high volume PCB assembly

8. BGA/QFN/DFN WITH X-ray insepction

9. IC programming/AOI/ICT/Functional test

FAQ:

Q1.What files for PCB quotation?

A:PCB files(gerber)

Q2.MOQ and what is the fastest delivery time?

A:There is no MOQ in Suntek. we are able to handle small as well as large volume production with flexibility. Samples need 3-5 working days,Mass production need 7-10 working days.

Q3.For PCB quotation, what files format do need?

A:Gerber, Protel 99SE, DXP, PADS 9.5, AUTOCAD,CAM350 are OK.

Q4.How to test PCB boards?

A:AOI, Fly probe testing, Text fixture testing, FQC etc for bare pcb.

We have advanced manufacturing equipments and technology,professional engineer team,purchasing team,quality team and management team to guarantee

the high quality products and on time delivery.Our products are widely used in industrial control,auto,telecommunications,medical equipment,consumer electronics and etc.

PCB Assembly equipments:
