Suntek Group is a leading supplier in EMS field with one-stop solution for PCB/FPC
assembly,Cable assembly,Mix technology assembly and Box-buildings.
Suntek Electronics Co., Ltd,as the major facility, located in Hunan Prov,China;
BLSuntek Electronics Co., Ltd,as the new facility,located in Kandal Prov,Cambodia.
Defining Industrial PCBs
Industrial PCBs differentiate on:
Operating Environments – Made for extreme industrial settings with wider temperature (-40°C to 105+°C), shock/vibration, humidity and other environmental demands.
Lifespan – Designed for high reliability over long product field life, often 10-15+ years of near continuous operations.
Criticality – High availability, functionality and safety criticality if the PCB fails. Whole industrial systems may rely on them.
Some examples of electronics using specially designed industrial class PCBs include:
Ruggedness, extended lifespan and high reliability distinguish industrial PCBs even though they may resemble commercial boards upon visual inspection. Their unique constraints lead to various design and manufacturing rules.
Substrates
| Layers: |
Rigid PCB 2 - 40 + Layers, Rigid-flex PCB 1 - 10Layers |
| Panel Size(max): |
21" x 24" |
| PCB Thickness: |
0.016" to 0.120" |
| Line & Spaces: |
0.003" / 0.003" Inner Layers; 0.004" Outer Layers |
| Hole Size: |
0.006" Thru Hole (Finished Size) and 0.004" Buried Via |
| Materials: |
FR4, High Tg, Rogers, Halogen-free material, Teflon, Polyimide |
| Surface Finishes: |
ENi/IAu, OSP, Lead-free HASL,Immersion Gold/Silver, Immersion Tin |
| Special Products: |
Blind/ Buried Via(HDI 2+N+2), Rigid Flex |
How are industrial PCBs different than commercial PCBs?
· Longer field deployment lifetimes (10-20 years)
· Required survival through harsh vibration, shock, moisture conditions
· High availability and uptime (>99%)
· Rigorous product testing and qualification
· Precision manufacturing process controls
· Traceability documentation Which exceeds commercial PCB environmental and lifespan demands.
What are some ways engineers design industrial PCB layouts differently?
Design techniques used for industrial printed circuit boards include:
- Component derating below absolute maximum levels
- Thermal simulation using finite element models
- Redundant connections and pathways
- Vibration damping edge mount connectors
- Conformal coating for moisture protection
- Thicker power and ground traces
- Double sided boards to withstand shock
- Extensive DFM analysis before release
Our supports
We ensure cost transparency, BOM cost breakdown sharing
We have components suppliers from the Global.
We have a written process to advise customers of any schdule delays or product quality problems,by:
(1)Customer service procedure
(2)RMA procedure
(3)8D reports
(4)PDCA(Plan-Do-Check-Action) in customer service
We respond to the complaints,issues and queries in 24 hours, by:
(1) Weekly reports
(2) Customer supporting team to review communication times
(3) Customer satisfaction questionnaire
Aftersales services:
(1) 1-year guarantee period for all of products
(2) FOC repair
(3) Quick compensation parts to replace defectives.
Packaging:
The Flexible PCB Assembly product will be packaged in a sturdy cardboard box to ensure safe transportation. The box will be sealed with tape to prevent any damage during shipping.
The product will also be wrapped in bubble wrap to provide extra protection against potential impact and vibration during transit.
Each box will be labeled with the product name, quantity, and handling instructions to facilitate easy identification and handling.
Shipping:
The product will be shipped via a reliable and trusted courier service to ensure timely and secure delivery to the customer.
The shipping address and contact information will be double-checked to ensure accurate delivery. The product will be insured during transit to protect against any unforeseen events.
A tracking number will be provided to the customer once the product has been shipped, allowing them to track their order and ensure its safe arrival.
Upon delivery, the customer will be required to sign for the package as proof of receipt.
Our core is "Quality wins Market, ldeas create the Future".
