Polyimide Flexible Printed Circuit Board 1-12 Layers 600mm X 1200mm
We have advanced manufacturing equipments,professional technology, professional engineer team,purchasing team,quality team and well trained operators to make sure the flex PCB with good&stable quality.
FPC Characters:
1.FPC provide better heat dissipation due to the streamline design of the polyimide laminates.
2.FPC offer better electrical performance because their low permittivity allows fast transmission of electrical signals and reduces the noise.
3.FPC offer a very long life time,it can be bent up to 500 million times and can be bent into many shapes
4.FPC can be with bigger size than rigid PCB,the width can be 500mm and lengths can be any as your request.
5.FPC is with very light weight and will not take much space.
FPC Capabilities:
| Item |
Capability |
| Min.Finished Board Thickness |
0.05mm |
| Max Board Size |
500mm*1200mm |
| Min Laser Drilled Hole Size |
0.025mm |
| Min Mechanical Drilled Hole Size |
0.1mm |
| Min. Trace Width/Spacing |
0.035mm/0.035mm |
| Min.Annular Ring of Single/Double-side Board |
0.075mm |
| Min.Inner Layer Annular Ring of Multi-layer Board |
0.1mm |
| Min.Outer Layer Annular Ring of Multi-layer Board |
0.1mm |
| Min Coverlay Bridge |
0.1mm |
| Min. Soldermask Opening |
0.15mm |
| Min.Coverlay Opening |
0.35mm*0.35mm |
| Min Single-ended Impedance Tolerance |
‘+/-7% |
| Min Differential Impedance Tolerance |
|
| Max Layer Count |
12L |
| Material Type |
PI,Kapton |
| Material Brand |
Shengyi,Taiflex,Thinflex,ITEQ,Allstar,Panasonic,Dupont,Jiujiang |
| Stiffener Material Type |
FR4,PI,PET,Steel,AI,Adhesive Tape,Nylon |
| Coverlay Thickness |
12.5um/25um/50um |
| Surface Finish |
ENIG,ENEPIG,OSP,Gold Plating,Gold Plating+ENIG,Gold Plating+OSP,Imm Silver,Imm Tin,Plating Tin |
FAQ:
Q1: What files do you use in PCB fabrication?
A1: Gerber, PCB,Drawings.
Q2: How do you make sure the quality?
A2: Our Product is all 100% E-tested .PCB Assembly are with 100% AOI,ICT,FT and Visual checking,100% X-ray for BGA.
Q3: Can we visit your company?
A3: Of course,Welcome to visit our company, Suntek located in Xingsha Industrial Park, Changsha,Hunan province, China.
Q4: What is the lead time?
A4: It takes 3-5 working days for sample, 7-10 working days for batch production based on files and quantity. It takes 15-20 working days for PCB assembly.
Q5: Will you keep our information and files secret?
A5: Sure,It is our basic principle to keep business secrets to protect our customers' designs.NDA can be signed at any time.
Q6. How to work with you?
A6: -Email and send us the PCB layout file, BOM list
- We will provide reply confirmation within 12 hours and reply to the offer within 3-5 days.
- Waiting for your company to confirm the price, order and payment terms.
- We will proceed the order.
