Suntek Group is a leading supplier in EMS field with one-stop solution for PCB/FPC
assembly,Cable assembly,Mix technology assembly and Box-buildings.
Suntek Electronics Co., Ltd,as the major facility, located in Hunan Prov,China;
BLSuntek Electronics Co., Ltd,as the new facility,located in Kandal Prov,Cambodia.
Capabilities overview:
|
Specifications
|
Details
|
|
Material type
|
FR-1, FR-4, CEM-1, aluminum clad
|
|
Material thickness ( mm)
|
0.4, 0.6, 0.8, 1.0, 1.2, 1.6, 2.0
|
|
Layer count
|
1 to 8 Layers
|
|
Max. Board size
|
23.00” x 35.00”(580mm*900mm)
|
|
IPC class
|
Class II, Class III , Class 1
|
|
Annular ring
|
5 mil/side or Greater (Min. Design)
|
|
Finish plating
|
Solder(HASL), Lead Free Solder(HASL), ENIG (Electroless nickel
immersion gold), OSP, immersion silver, immersion tin, immersion nickel,
hard gold, other
|
|
Copper weight
|
0.5OZ-2OZ
|
|
Trace/space width
|
3 Mils or greater
|
|
Drill clearance
|
0.1mm(laser drilling)
|
|
Plated slots
|
0.036 or greater
|
|
Smallest hole (finished)
|
0.1mm or greater
|
|
Gold fingers
|
1 to 4 Edge (30 to 50 Micron Gold)
|
|
SMD pitch
|
0.080” - 0.020” - 0.010”
|
|
Solder mask type
|
LPI Glossy, LPI-Matte, SR1000
|
|
Solder mask color
|
Green, red, blue, black, white, yellow
|
|
Legend color
|
White, yellow, black, red, blue
|
|
CNC route point
|
Any
|
|
Minimum route width
|
0.031”
|
|
Scoring
|
Straight lines, jump scoring, panel edge to edge, CNC*
|
|
Body gold
|
HARD*, IMMERSION* (up to 50 MICRON GOLD)
|
|
Data file format
|
Gerber 274x with embedder aperture
|
|
FAB. Drawing format
|
DXF, HPGL, DWG, PDF, Gerber
|
|
E.T testing
|
Flying probe, single sided, 1up plate, clamp shell, net list
|
|
Counter sink/counter bore
|
Available up to 0.250 Diameter
|
|
Control impedance
|
Yes
|
|
Blind vias/buried vias
|
Yes
|
|
Peelable mask
|
Yes
|
|
Carbon
|
Yes
|
Flexible PCB, also known as flex prints or flex circuits, is a special type of circuit board that you can bend into the desired shape. They are widely used for high-density and high-temperature applications. The flex designs are composed of polyimide or a transparent polyester film as a substrate material that comes with high heat resistance which makes it a right fit for solder mounting components.
Applications:
The flexible circuit boards are a right match for applications that require better performance, high accuracy, precision, and regular flexing. Applications of flexible circuit boards include:
- Antilock brakes
- Cameras
- Fuel pumps
- Ultrasound probes
- Semiconductor test
- Medical devices
- Motion systems
- Satellites
- Avionics
- Battery packs
- Manufacturing devices
- Airbag systems
Packing and Shipping:
Flexible PCB Assembly Packaging and Shipping
Packaging:
The Flexible PCB Assembly product will be packaged in a sturdy cardboard box to ensure safe transportation. The box will be sealed with tape to prevent any damage during shipping.
The product will also be wrapped in bubble wrap to provide extra protection against potential impact and vibration during transit.
Each box will be labeled with the product name, quantity, and handling instructions to facilitate easy identification and handling.
Shipping:
The product will be shipped via a reliable and trusted courier service to ensure timely and secure delivery to the customer.
The shipping address and contact information will be double-checked to ensure accurate delivery. The product will be insured during transit to protect against any unforeseen events.
A tracking number will be provided to the customer once the product has been shipped, allowing them to track their order and ensure its safe arrival.
Upon delivery, the customer will be required to sign for the package as proof of receipt.
Our supports
We ensure cost transparency, BOM cost breakdown sharing
We have components suppliers from the Global.
We have a written process to advise customers of any schdule delays or product quality problems,by:
(1)Customer service procedure
(2)RMA procedure
(3)8D reports
(4)PDCA(Plan-Do-Check-Action) in customer service
We respond to the complaints,issues and queries in 24 hours, by:
(1) Weekly reports
(2) Customer supporting team to review communication times
(3) Customer satisfaction questionnaire
Aftersales services:
(1) 1-year guarantee period for all of products
(2) FOC repair
(3) Quick compensation parts to replace defectives.
Our Target
We are always trying to supply competitive price,high quality,quick-delivery products.
