Name: Printed Circuit Board Turnkey PCB Electronics White Silk PVC Cable ENIG Surface Finish
Brand: Suntek Electronics Co., Ltd.
SKU: F9632-12
Price: 50.00 USD
Availability: InStock

Home > products > Turnkey PCB Assembly >

Printed Circuit Board Turnkey PCB Electronics White Silk PVC Cable ENIG Surface Finish

printed circuit board turnkey

turnkey pcb electronics

printed circuit board turnkey electronics

Place of Origin:

China

Brand Name:

Suntek

Certification:

ISO9001, ISO13485, TS16949 and UL E476377

Model Number:

F9632-12

Request A Quote

Printed Circuit Board Turnkey PCB Electronics White Silk PVC Cable ENIG Surface Finish

Product Details

Maximum Size:

600mm*1200mm

Cable:

PVC, LSZH, OFNP, OFNR, Hytrel

Inspection Standard:

IPC Class II/ IPC Class III

Lead Time:

3-5 Days

Suface Finish:

ENIG

Surface Treatment:

OSP: 0.5-0.5um

Silk:

White

Pcb Outline:

Square, Circle, Irregular(with Jigs)

Payment & Shipping Terms

Minimum Order Quantity

5pcs

Packaging Details

Vacuum,Anti-static,ESD,Cartons

Delivery Time

3-6 weeks

Payment Terms

T/T,Paypal

Supply Ability

100pcs/hour

Printed Circuit Board Turnkey PCB Electronics White Silk PVC Cable ENIG Surface Finish

SMT Parameters:

Technology	Circuit	PCB/Flex/Metal PCB/Rigid-Flex	Parameter	Assembly Side	Single/Double
	Process	SMT		Min Size	10mm * 10mm
		THT		Max Size	410mm * 350mm
		Punch		Thickness	0.38mm ~ 6.00mm
		In-circuit Test Function Test		Min Chip	0201 chip
		Glue,Burn-in Conformal Coating		Fine-pitch	0.20mm
		BGA Re-work		BGA ball size	0.28mm

Technology Involved:

H 高	◆SMT+ICT+THT+FT ◆SMT+ICT+THT+Harness+Assembly+FT	◆SMT machine(for printing,pick place,reflow soldering) ◆THT machine(for wave soldering) ◆Terminal machine...	◆AOI ◆X-RAY ◆injection molding machine ◆AI(Automatic Inserting machine)...
M 中	◆SMT+ICT ◆THT+FT ◆SMT+THT ◆THT+Harness+FT ◆Assembly+FT	◆ Genera SMD+DIP ◆ DIP parts+ Harness ◆SMD+DIP+Harness without injection molding	◆≤0201 SMD ◆BGA,LGA,FBGA,LCC+LGA ◆Harness+injection molding ◆Conformal coating
S 低	◆纯SMT(Only SMT) ◆纯THT(Only THT) ◆纯线束(Only Harness) ◆纯组装(Only Assembly)	◆代工代料 Material+ Assembly	◆设计+代工代料 Design+Meterial+Assembly
	low	higher	highest

Special Technology Involved

◆ IC Programming

◆ BGA rework

◆ Chip on Board/COB

◆ Eutectic soldering

◆ Auto-Gluing

◆ Conformal Coating

Printed Circuit Board Turnkey PCB Electronics White Silk PVC Cable ENIG Surface Finish 0

Assemly Flow Chart:

Printed Circuit Board Turnkey PCB Electronics White Silk PVC Cable ENIG Surface Finish 1

Printed Circuit Board Turnkey PCB Electronics White Silk PVC Cable ENIG Surface Finish 2

Suntek Group is a leading supplier in EMS field with one-stop solution for PCB/FPC assembly,Cable assembly,Mix technology assembly and Box-buildings.

Suntek Electronics Co., Ltd,as the major facility, located in Hunan Prov,China;

BLSuntek Electronics Co., Ltd,as the new facility,located in Kandal Prov,Cambodia.With ISO9001:2015,ISO13485:2016,IATF 16949:2016 and UL E476377 certified,.We deliver qualified products with competitive price to clients all over the world.
