Suntek Group is a leading supplier in EMS field with one-stop solution for PCB/FPC
assembly,Cable assembly,Mix technology assembly and Box-buildings.
Suntek Electronics Co., Ltd,as the major facility, located in Hunan Prov,China;
BLSuntek Electronics Co., Ltd,as the new facility,located in Kandal Prov,Cambodia.
Product Description:
|
Capabilities overview:
|
|
|
Layers:
|
Rigid PCB 2 - 24 + Layers, Rigid-flex PCB 1 - 10Layers
|
|
Panel Size(max):
|
21" x 24"
|
|
PCB Thickness:
|
0.016" to 0.120"
|
|
Line & Spaces:
|
0.003" / 0.003" Inner Layers; 0.004" Outer Layers
|
|
Hole Size:
|
0.006" Thru Hole (Finished Size) and 0.004" Buried Via,
|
|
Materials:
|
FR4, High Tg, Rogers, Halogen-free material, Teflon, Polyimide
|
|
Surface Finishes:
|
ENi/IAu, OSP, Immersion Silver, Immersion Tin
|
|
Special Products:
|
Blind/ Buried Via(HDI 2+N+2), Rigid Flex
|
Key Features:
High-quality FR-4 material for reliable and efficient assembly
Available in white, black, and yellow silkscreen colors for enhanced visual appeal
Compact dimensions of 76*31*4.5mm (L*W*H) for versatile use in various medical devices
Specialized service for medical system PCB integration and healthcare device electronics assembly
Ensures accurate and reliable results for medical offices, testing facilities, and medical device manufacturers
In conclusion,PCB Assembly is a highly advanced and specialized product that is revolutionizing the healthcare industry. Its use in medical offices, testing facilities, and medical devices ensures reliable and accurate results, making it an essential component in the field of medicine.
Customization:
At Suntek, we specialize in providing customized PCB assembly services for medical devices. Our team of experts has years of experience in healthcare PCB assembly and is dedicated to ensuring the highest quality of production for health monitoring devices.
Our PCB assembly service offers a measurement range of 30℃~+70℃ (-22℉~158℉), making it suitable for a wide range of medical devices that require precise temperature control. We also offer the flexibility of double side and multilayer assembly, allowing for more complex and compact designs for medical devices.
With a thickness of 0.8mm, our PCB assembly service is ideal for compact and lightweight medical devices. We also offer customization options for layers, ranging from 1 to 64 layers, to meet the specific requirements of our clients.
Trust us to provide top-notch medical device electronic manufacturing with our healthcare PCB assembly service. Contact us today to learn more about our health monitoring PCB production capabilities and how we can help bring your medical device to life.
Packing and Shipping:
PCB Assembly - Packaging and Shipping
Our PCB Assembly products are carefully packaged and shipped to ensure their safe delivery to our customers. We understand the importance of maintaining the quality and integrity of our products, especially in the medical industry. That's why we follow strict packaging and shipping guidelines to ensure that our products arrive at their destination in perfect condition.
Packaging
Each Medical PCB Assembly is first wrapped in anti-static bubble wrap to protect it from any physical damage during transportation. It is then placed in a sturdy, custom-made cardboard box with appropriate labeling and markings to indicate its fragility and handling instructions.
In addition, we use specialized foam inserts to secure the PCB assembly in place and prevent any movement or shifting within the box. This ensures that the delicate electronic components are well-protected and do not get damaged during transit.
Shipping
We work with trusted shipping partners to deliver our Medical PCB Assembly products to our customers. Our shipping partners are experienced in handling delicate and sensitive electronic equipment, and they follow proper handling and transportation procedures to ensure the safety of our products.
We also provide insurance for our shipments, so in the unlikely event of any damage during transit, our customers are fully covered.
Customized Packaging
At the request of our customers, we offer customized packaging solutions for our Medical PCB Assembly products. This can include additional packaging materials to provide extra protection or specific labeling and markings for easier handling and identification.
We understand that every customer has unique requirements, and we are happy to work with them to provide customized packaging solutions that meet their needs.
With our meticulous packaging and shipping processes, you can be assured that your Medical PCB Assembly products will arrive at their destination safely and in pristine condition. Contact us today to learn more about our packaging and shipping options for our Medical PCB Assembly products.
FAQ:
Medical PCB Assembly is a type of printed circuit board assembly that is specifically designed for use in medical equipment and devices.
Q:What are the main components of Medical PCB Assembly?
A:The main components of Medical PCB Assembly include a printed circuit board, electronic components such as resistors and capacitors, and soldering materials.
Q:What are the benefits of using Medical PCB Assembly?
A:Medical PCB Assembly offers high reliability and precision, making it suitable for use in critical medical equipment.
It is designed and manufactured to meet strict safety and quality standards, ensuring the safety and effectiveness of medical devices.
Medical PCB Assembly can be customized to meet the specific requirements and specifications of different medical devices, ensuring optimal performance.
It is compact and lightweight, making it ideal for use in small and portable medical devices.
Medical PCB Assembly also offers cost-efficiency, as it can be mass-produced and requires minimal maintenance.
Q:What types of medical devices can use Medical PCB Assembly?
A:Medical PCB Assembly can be used in a wide range of medical devices, including diagnostic equipment, monitoring devices, imaging systems, surgical instruments, and more.
Q:What are the quality control measures for Medical PCB Assembly?
A:Medical PCB Assembly is subject to strict quality control measures, including inspection of components, soldering quality, and functionality testing.
It may also undergo additional testing, such as temperature and humidity tests, to ensure its durability and performance in various environments.
Manufacturers of Medical PCB Assembly may also follow certain industry standards and regulations, such as ISO 13485 for medical devices.
Our supports
We ensure cost transparency, BOM cost breakdown sharing
We have components suppliers from the Global.
We have a written process to advise customers of any schdule delays or product quality problems,by:
(1)Customer service procedure
(2)RMA procedure
(3)8D reports
(4)PDCA(Plan-Do-Check-Action) in customer service
We respond to the complaints,issues and queries in 24 hours, by:
(1) Weekly reports
(2) Customer supporting team to review communication times
(3) Customer satisfaction questionnaire
Aftersales services:
(1) 1-year guarantee period for all of products
(2) FOC repair
(3) Quick compensation parts to replace defectives.
